Adjustable To Other Vertical File Systems

	Adjustable To Other Vertical File Systems
	Contemporary Styling
	Lockable For Complete Security
	15 Second Retrieval Of Any Document
	Sturdy, All-Welded Construction
	Adaptable To English Or Metric Sizes

For generations, large architectural and engineering documents have been stored in cumbersome flat file drawers containing up to 100 drawings per drawer. Anyone who has ever retrieved and returned the bottom drawing to a hundred drawing flat file is aware of the time required to retrieve the drawing as well as the difficulty and time required to return it to its proper filing sequence. There is also the danger of damaging the document as it is removed and returned to the flat file. Many of the European countries as well as Canada have developed an efficient, safe and economical way to store large documents. The vertical plan file system offers many advantages over the archaic flat file.

Vertical filing systems such as the DiAZiT Stylefile hold up to 1,540 drawings per file and occupy only 3.75 square feet of floor space. A 5-drawer file cabinet occupies 6 or more square feet of floor space and 2 units must be stacked on top of each other to hold 1,000 documents (100 per drawer). It is also inconvenient to retrieve drawings from the top drawer and the bottom drawer of flat files, and an additional 2 to 3 feet are required in floor space to extend the drawers for filing or retrieval of documents. With the DiAZiT vertical file system, documents are placed on polyester hanging strips that hold them in a vertical position free of wrinkling and dog-earring comers. Any document may be retrieved in 15 seconds easily and safely for both the user and the document.

The DiAZiT Stylefile offers the
convenience, economy, and document safety of the proven vertical filing system, yet it is priced competitively with flat files.
The DiAZiT Stylefile is definitely the
plan file system of the future.

Specifications:

Size 24" x 36"	Size 30" x 42"	Size 36" x 48"
PN7800 Beige PN7801 - Grey	PN7900 Beige PN7901 Grey	PN7950 Beige PN 7951 Grey

Ship Wt. 143 lbs.	Ship Wt. 165 lbs.	Ship Wt. 305 lbs.
H x D x W	H x D x W	H x D x W
45.0" X 16.75" X 29.75"	50.75" X 16.75" X 36"	45.0" X 16.75" X 55.75"
Prong Diameter 15/16" *Maximum Wt. 200 lbs.	Prong Diameter 15/16" *Maximum Wt. 200 lbs.	Prong Diameter 15/16" *Maximum Wt. 200 lbs.

Recommended Sheet Capacity *(Not to exceed maximum weight listed above.)	Total Sheets
	Vellum	3 mil	4 mil
With .003 Carrier Strip	1540	1540	1375
With .005 Carrier Strip	1200	1200	1100

The special design of the Stylefile allows movement or addition of extra prongs by the user, giving complete compatibility with most existing systems. Different size drawings can be intermingled in order to meet the user's index system.

FEATURES:

	Sturdy, yet stylish, *DiAZiT Stylefile* represents the ultimate in mix and match plan/drawing filing systems, with a variety of color combinations to complement any drawing office decor.
	Strong, all-welded powder coat finish steel frame for maximum rigidity and scratch resistant decorative panels guarantee years of trouble-free life.
	The two-stage door opening system enables drawings to be located and retrieved within 15 seconds.
	A clever lid design enables the cabinets to be stored either back to back or flush against the wall, and the lids are lockable for complete security.

For complete safety, all Stylefile cabinets incorporate special stabilizing feet which extend as the front door of the cabinet is opened. This supports the full weight of drawings without danger of toppling over. No heavy anti-tilt weights are needed for stability.
